Description
Product Description
Intel 10th Gen Core i5-10400 Processor
This Intel Core I5-10400 10th Gen Processor comes with an Intel UHD Graphics 630 plates. This new 10th word Comet Lake micro architecture is manufactured with the 14nm process that comes with six cores but lacks in Hyper Threading. As this chip is streamlined to the rearmost Memoirs modification,
Fastening on this, all the major motherboard manufacturers have formerly started BIOS updates for their 400-series lineup. These Processors also support 64- bit computing on Intel armature bear an Intel 64 armature– enabled Memoirs.
(12M Cache- up to 4.30 GHz) |
|
| Essentials | |
| Product Collection | 10th Generation Intel® Core™ i5 Processors |
| Code Name | Products formerly Comet Lake |
| Vertical Segment | Desktop |
| Processor Number | i5-10400 |
| Status | Launched |
| Launch Date | Q2’20 |
| Lithography | 14 nm |
| Use Conditions | PC/Client/Tablet |
CPU Specifications |
|
| Total Cores | 6 |
| Total Threads | 12 |
| Max Turbo Frequency | 4.30 GHz |
| Intel® Turbo Boost Technology 2.0 Frequency‡ | 4.30 GHz |
| Processor Base Frequency | 2.90 GHz |
| Cache | 12 MB Intel® Smart Cache |
| Bus Speed | 8 GT/s |
| TDP | 65 W |
| Supplemental Information | |
| Embedded Options Available | No |
Memory Specifications |
|
| Max Memory Size (dependent on memory type) | 128 GB |
| Memory Types | DDR4-2666 |
| Max # of Memory Channels | 2 |
| Max Memory Bandwidth | 41.6 GB/s |
| ECC Memory Supported ‡ | No |
Processor Graphics |
|
| Processor Graphics ‡ | Intel® UHD Graphics 630 |
| Graphics Base Frequency | 350 MHz |
| Graphics Max Dynamic Frequency | 1.10 GHz |
| Graphics Video Max Memory | 64 GB |
| 4K Support | Yes | at 60Hz |
| Max Resolution (HDMI)‡ | 4096 x 2160@30Hz |
| Max Resolution (DP)‡ | 4096 x 2304@60Hz |
| Max Resolution (eDP – Integrated Flat Panel)‡ | 4096 x 2304@60Hz |
| DirectX* Support | 12 |
| OpenGL* Support | 4.5 |
| Intel® Quick Sync Video | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Clear Video HD Technology | Yes |
| Intel® Clear Video Technology | Yes |
| # of Displays Supported ‡ | 3 |
| Device ID | 0x9BC8 / 0x9BC5 |
Expansion Options |
|
| Scalability | 1S Only |
| PCI Express Revision | 3 |
| PCI Express Configurations ‡ | Up to 1×16 | 2×8 | 1×8+2×4 |
| Max # of PCI Express Lanes | 16 |
| Package Specifications | |
| Sockets Supported | FCLGA1200 |
| Max CPU Configuration | 1 |
| Thermal Solution Specification | PCG 2015C |
| TJUNCTION | 100°C |
| Package Size | 37.5mm x 37.5mm |
Advanced Technologies |
|
| Intel® Optane™ Memory Supported ‡ | Yes |
| Intel® Thermal Velocity Boost | No |
| Intel® Turbo Boost Max Technology 3.0 ‡ | No |
| Intel® Turbo Boost Technology ‡ | 2 |
| Intel vPro® Platform Eligibility ‡ | No |
| Intel® Hyper-Threading Technology ‡ | Yes |
| Intel® Virtualization Technology (VT-x) ‡ | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes |
| Intel® VT-x with Extended Page Tables (EPT) ‡ | Yes |
| Intel® Transactional Synchronization Extensions | No |
| Intel® 64 ‡ | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel® SSE4.1 | Intel® SSE4.2 | Intel® AVX2 |
| Idle States | Yes |
| Enhanced Intel Speed Step® Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Identity Protection Technology ‡ | Yes |
| Intel® Stable Image Platform Program (SIPP) | No |
Security & Reliability |
|
| Intel® AES New Instructions | Yes |
| Secure Key | Yes |
| Intel® Software Guard Extensions (Intel® SGX) | Yes with Intel® ME |
| Intel® OS Guard | Yes |
| Intel® Trusted Execution Technology ‡ | No |
| Execute Disable Bit ‡ | Yes |
| Intel® Boot Guard | Yes |
Intel 10th Gen Core i5-10400 Processor
This i5-10400 Processor comes with an Intel UHD Graphics 630 graphics. it nicely fits into any Intel 400-series motherboard. Focusing on this, all the major motherboard manufacturers have already started BIOS updates for their 400-series lineup. Core Benefits of the Processor has the SmartCache of 12 MB containing 6 cores and 12 threads. With the bus speed of 8 GT/s DMI3, it has thermal design power (TDP) rating of 65W. Considering the memory this processor has dual-channel of max 128GB of the size that supports up to DDR4-2666 bus speed.
Intel Core i5 10400 Processor comes with Intel UHD Graphics 630 graphics. it nicely fits into any Intel 400-series motherboard. Focusing on this, all the major motherboard manufacturers have already started BIOS updates for their 400-series lineup.
It has a Smart Cache of 12 MB containing 6 cores and 12 threads. With a bus speed of 8 GT/s DMI3, it has thermal design power (TDP) rating of 65W. Considering the memory this processor has a dual-channel of max 128GB of size that supports up to DDR4-2666 bus speed.
